Subaru 2016 Outback Manual: A Comprehensive Overview
This manual‚ in English‚ details the 2016 Subaru Outback’s operation and key features. It’s a resource for all owners‚ offering guidance and essential information.
Welcome to the world of the 2016 Subaru Outback! This versatile vehicle blends the capability of an SUV with the comfort of a passenger car‚ making it ideal for both daily commutes and adventurous journeys. This manual serves as your comprehensive guide to understanding and operating your Outback effectively.
The 2016 Outback builds upon Subaru’s renowned symmetrical all-wheel drive system‚ providing superior traction and control in various driving conditions. Whether navigating snowy roads or tackling challenging terrain‚ the Outback delivers confidence and stability. This manual will detail how to maximize the benefits of this system.
Inside‚ you’ll find a spacious and well-appointed interior designed for comfort and convenience. From the available STARLINK multimedia system to advanced safety features like EyeSight‚ the Outback offers a range of technologies to enhance your driving experience. This guide will walk you through each feature‚ ensuring you get the most out of your vehicle.
Understanding the 2016 Outback Trim Levels
The 2016 Subaru Outback was offered in several distinct trim levels‚ each catering to different preferences and budgets. The base 2.5i model provides a solid foundation of features‚ including Subaru’s symmetrical all-wheel drive and a comfortable interior. Stepping up to the Premium trim adds enhancements like heated front seats and a power driver’s seat.
For those seeking more luxury‚ the Limited trim boasts leather upholstery‚ a premium audio system‚ and additional convenience features. At the top of the range‚ the Touring trim offers ultimate refinement with features like a power rear gate and exclusive styling cues.
This manual applies to all trim levels unless specifically noted. While certain features may vary depending on the model‚ the core operating principles remain consistent. Refer to your vehicle’s specific window sticker or owner’s information to confirm the exact features included in your Outback.
Key Features and Specifications
The 2016 Subaru Outback showcases a robust 2.5-liter four-cylinder engine delivering 175 horsepower‚ paired with Subaru’s renowned symmetrical all-wheel drive system for superior handling in all conditions. Standard features include a rearview camera‚ Bluetooth connectivity‚ and a user-friendly infotainment system.
Cargo capacity is a standout‚ offering 35.5 cubic feet behind the rear seats‚ expanding to 73.3 cubic feet with the rear seats folded down. Safety is paramount‚ with standard features like anti-lock brakes and a suite of airbags.
Optional features‚ depending on the trim level‚ include the EyeSight Driver Assist Technology‚ a premium Harman Kardon audio system‚ and a power moonroof. The Outback’s ground clearance of 8.7 inches enhances its capability for light off-road adventures. This manual details operation of all these features.

Operating Your 2016 Subaru Outback
This section provides detailed instructions for safely and effectively operating your 2016 Outback‚ covering everything from starting the engine to utilizing its advanced features.
Starting and Stopping the Engine
Starting your 2016 Subaru Outback is a straightforward process. Ensure the parking brake is engaged and the gear selector is in ‘P’ (Park). Insert the key into the ignition or‚ if equipped‚ press the Start/Stop button while firmly pressing the brake pedal. The engine will then crank and start.
To stop the engine‚ gently apply the brake pedal and shift the gear selector to ‘P’. Then‚ turn the ignition key to the ‘LOCK’ position or press the Start/Stop button once. Allow the engine to fully stop before removing the key or exiting the vehicle.
Important considerations: Never start or stop the engine while in gear. Always ensure the parking brake is engaged‚ especially on inclines. Familiarize yourself with the instrument panel indicators to monitor engine status during startup and shutdown. A smooth‚ controlled process extends engine life and ensures safety.
Understanding the All-Wheel Drive System
The 2016 Subaru Outback features Symmetrical All-Wheel Drive (AWD)‚ a key component of its renowned capability. Unlike many systems‚ Subaru’s AWD is full-time‚ continuously powering all four wheels for enhanced stability and traction. This system proactively distributes torque‚ responding to changing road conditions before wheel slip occurs.
The AWD system doesn’t require driver intervention; it operates automatically. Sensors constantly monitor wheel speed and distribute power accordingly. During normal driving‚ power is typically split 60/40 front to rear. However‚ this distribution can dynamically adjust up to 50/50 for optimal grip in slippery conditions like snow‚ ice‚ or gravel.
No special modes or buttons are needed to activate the AWD system. It’s always working to provide a secure and confident driving experience. Regular maintenance‚ as outlined in the maintenance schedule‚ is crucial for optimal AWD performance.
Using the Lineartronic CVT Transmission
The 2016 Subaru Outback utilizes a Lineartronic Continuously Variable Transmission (CVT). Unlike traditional automatic transmissions with fixed gears‚ a CVT provides seamless and virtually stepless gear ratios. This results in smoother acceleration and improved fuel efficiency.
The CVT operates differently than a conventional automatic. You may notice the engine speed holding at a specific RPM during acceleration‚ rather than shifting through gears. This is normal CVT behavior and optimizes engine performance. The transmission features simulated shift points for a more familiar driving feel‚ selectable via “S” mode.
“S” mode provides quicker response and increased engine braking for more spirited driving. Regular CVT fluid changes‚ as per the maintenance schedule‚ are vital for longevity and proper function. Avoid prolonged operation at high speeds or heavy loads without proper maintenance.
Dashboard Symbols and Warning Lights
The 2016 Subaru Outback’s instrument panel displays various symbols and warning lights‚ communicating the vehicle’s status. Understanding these indicators is crucial for safe operation. Solid lights generally indicate a system is actively engaged‚ while flashing lights often signal a potential issue requiring attention.
Key warning lights include the check engine light (malfunction indicator)‚ oil pressure warning‚ brake system warning‚ and airbag system warning. A low tire pressure warning illuminates when one or more tires are significantly underinflated. The ABS light indicates a problem with the Anti-lock Braking System.
Refer to the dedicated warning light section in this manual for detailed explanations of each symbol. Ignoring warning lights can lead to more serious mechanical problems. If a warning light remains illuminated after addressing the obvious cause‚ consult a Subaru dealer for diagnosis and repair.

Maintenance and Care
Regular maintenance ensures your 2016 Outback’s longevity and performance. This section details recommended schedules for fluid checks‚ tire care‚ and battery upkeep.
Recommended Maintenance Schedule
Maintaining your 2016 Subaru Outback requires adherence to a specific schedule to ensure optimal performance and reliability. Every 5‚000 miles (or 6 months‚ whichever comes first)‚ an oil change and filter replacement are crucial. Inspecting and rotating tires is also recommended at this interval‚ alongside a thorough inspection of all fluid levels – coolant‚ brake fluid‚ power steering‚ and windshield washer fluid.
At 15‚000 miles‚ add to the previous checks a cabin air filter replacement and a more detailed inspection of the brake system‚ including pads‚ rotors‚ and lines. Around 30‚000 miles‚ the engine air filter should be replaced‚ and the fuel filter inspected. A coolant flush is typically recommended around 60‚000 miles‚ along with a spark plug replacement.
Always refer to the complete maintenance schedule in your owner’s manual for precise intervals and specific requirements based on your driving conditions. Following this schedule will help prevent costly repairs and extend the life of your Outback.
Checking and Changing Fluids (Oil‚ Coolant‚ Brake Fluid)
Regularly checking and maintaining your 2016 Outback’s fluids is vital for its health. For oil‚ check the dipstick with the engine off; add if low‚ and change every 5‚000-7‚500 miles with a quality filter. Coolant levels should be inspected when the engine is cold‚ ensuring it’s at the ‘Full’ mark – a flush is recommended every 60‚000 miles.
Brake fluid is critical for stopping power; check the reservoir level and look for contamination. If it appears dark or murky‚ a flush is necessary. Power steering fluid should also be checked periodically‚ topping up as needed. Windshield washer fluid is simple – fill when low!
Always use the Subaru-recommended fluid types. Improper fluids can cause damage. Dispose of used fluids responsibly at a recycling center.
Tire Maintenance and Replacement
Maintaining proper tire pressure is crucial for safety and fuel efficiency in your 2016 Outback. Check pressures monthly using a reliable gauge‚ and inflate to the recommended PSI found on the driver’s side doorjamb sticker – not the tire sidewall. Regularly inspect tires for wear‚ damage (cuts‚ bulges)‚ and uneven tread.

Rotate tires every 5‚000-7‚500 miles to promote even wear. Tread depth is vital; use the penny test – if you can see all of Lincoln’s head‚ it’s time for replacement. When replacing‚ ensure tires match in size and type.
Subaru’s symmetrical all-wheel drive benefits from matched tires. Properly torqued lug nuts are essential after any tire work. Consider winter tires for optimal performance in snowy conditions.
Battery Maintenance and Jump Starting
Your 2016 Outback’s battery provides essential power. Regularly inspect the battery terminals for corrosion; clean with a baking soda and water solution if necessary‚ ensuring the vehicle is off. A slow-charging battery charger can help maintain optimal charge during extended periods of inactivity‚ preventing sulfation.
If the battery is drained‚ jump-starting is possible‚ but follow the correct procedure to avoid damage. Use jumper cables and a functioning vehicle. Connect positive (+) to positive‚ then negative (-) to a grounded metal part of the disabled Outback – not the negative terminal.
Start the assisting vehicle‚ let it run for a few minutes‚ then attempt to start the Outback. Disconnect cables in reverse order. If issues persist‚ consult a Subaru technician.

In-Car Technology and Features
Explore the advanced tech within your 2016 Outback! This section details STARLINK‚ Bluetooth‚ navigation‚ and the innovative EyeSight driver assist system functionalities.
Using the STARLINK Multimedia System
The 2016 Subaru Outback’s STARLINK system is your central hub for entertainment and connectivity. Access features through the touchscreen display‚ controlling audio‚ climate‚ and vehicle settings with ease. Familiarize yourself with the home screen layout‚ navigating through icons for radio‚ smartphone integration‚ and available apps.
Smartphone Integration: Connect your compatible smartphone via Bluetooth or USB to utilize Apple CarPlay or Android Auto. This allows you to access navigation‚ music‚ and communication features directly on the STARLINK display‚ minimizing distractions while driving.
Navigation: If equipped‚ the STARLINK navigation system provides turn-by-turn directions‚ real-time traffic updates‚ and points of interest. Input destinations using voice commands or the touchscreen keyboard. Regularly update the map data for the most accurate information.
Audio Options: Enjoy a variety of audio sources‚ including AM/FM radio‚ SiriusXM satellite radio (subscription required)‚ USB-connected devices‚ and Bluetooth streaming. Customize your audio experience with equalizer settings.
Voice Control: Utilize voice commands to control various STARLINK functions hands-free‚ enhancing safety and convenience.
Bluetooth Pairing and Operation

Connecting your smartphone to your 2016 Subaru Outback via Bluetooth enables hands-free calling‚ audio streaming‚ and access to compatible apps through the STARLINK system. To initiate pairing‚ navigate to the Bluetooth settings within the STARLINK multimedia system menu. Ensure your smartphone’s Bluetooth is enabled and set to discoverable mode.
Pairing Process: Select “Add Device” on the Outback’s display. Your vehicle will search for available Bluetooth devices. Select your smartphone from the list when it appears. You may be prompted to enter a PIN code on both your phone and the vehicle – confirm the code matches.
Operation: Once paired‚ your smartphone’s contacts and call history will be accessible through the STARLINK system. Answer and end calls using the steering wheel controls or the touchscreen. Stream music wirelessly from your phone’s music library or streaming services. Manage connected devices within the Bluetooth settings.
Multiple Devices: The system can store multiple paired devices‚ allowing seamless switching between users. Remember to delete unused devices to maintain optimal performance.
Navigation System Guide

The 2016 Subaru Outback’s navigation system‚ integrated within the STARLINK multimedia system‚ provides turn-by-turn directions‚ points of interest (POI) searches‚ and real-time traffic updates (subscription may be required). To begin‚ ensure the navigation system has a clear view of the sky for GPS signal acquisition.
Entering a Destination: You can input destinations by address‚ POI category (restaurants‚ gas stations)‚ or coordinates. Utilize the touchscreen keyboard or voice recognition for input. The system will calculate the optimal route based on your preferences – fastest‚ shortest‚ or avoiding tolls.

During Navigation: The system provides visual and audible guidance. The map display shows your current location‚ route‚ and upcoming maneuvers. Traffic information‚ if subscribed‚ is displayed on the map. Recalculation occurs automatically if you deviate from the route.
Map Settings: Customize the map display to your liking – adjust zoom level‚ orientation‚ and information shown. Regularly update the map data to ensure accuracy and access to the latest road information.
Understanding EyeSight Driver Assist Technology
Subaru’s EyeSight Driver Assist Technology‚ standard on many 2016 Outback trims‚ utilizes stereo camera technology to enhance safety and driver awareness. It functions as a second pair of eyes‚ constantly monitoring the road ahead.
Key Features: Adaptive Cruise Control maintains a set speed and distance from the vehicle ahead. Pre-Collision Braking warns you of potential collisions and can automatically apply the brakes. Lane Departure Warning alerts you if you unintentionally drift out of your lane. Lane Keeping Assist provides steering assistance to keep you centered.
Important Notes: EyeSight is a driver assist system‚ not a replacement for attentive driving. Weather conditions (heavy snow‚ rain) and road conditions can affect performance. Regularly clean the camera windshield for optimal functionality. Familiarize yourself with the system’s limitations and settings.
System Activation/Deactivation: EyeSight can be toggled on or off via a dedicated button on the steering wheel. A warning light on the dashboard indicates system status.

Safety Features and Procedures
This section details crucial safety systems within your 2016 Outback‚ including airbags‚ emergency protocols‚ and proper child safety seat installation guidelines.
Airbag System Information
The 2016 Subaru Outback is equipped with a sophisticated airbag system designed to provide crucial protection during a collision. This system includes front airbags for both driver and passenger‚ as well as side curtain airbags protecting occupants in both rows. Understanding how this system functions is paramount for your safety.
Airbags are designed to deploy in moderate to severe frontal impacts‚ and in certain side impact scenarios. Deployment is triggered by sensors that detect the severity of the collision. It’s important to remember that airbags supplement seatbelts; they do not replace them. Always ensure all occupants are properly restrained with seatbelts.
Never place rear-facing child seats in the front passenger seat if the airbag cannot be deactivated. Doing so can result in severe injury or death. Refer to the child safety seat installation section for detailed guidance. Regularly inspect the airbag system for any signs of malfunction‚ and consult a Subaru dealer for any necessary repairs or inspections. Proper maintenance ensures optimal performance when you need it most.
Emergency Procedures and Roadside Assistance
In the event of an emergency‚ your safety is the top priority. If involved in an accident‚ first ensure your own safety and the safety of any passengers. Check for injuries and‚ if possible‚ move the vehicle to a safe location away from traffic. Contact emergency services immediately if injuries are severe or if the situation requires professional assistance.
Subaru provides roadside assistance to Outback owners. This service can help with jump starts‚ tire changes‚ fuel delivery‚ and towing. Keep your vehicle identification number (VIN) and insurance information readily available when contacting roadside assistance. Familiarize yourself with the location of your spare tire‚ jack‚ and lug wrench.
Knowing basic emergency procedures‚ like how to activate hazard lights and properly signal for help‚ can significantly improve your safety. Regularly review this manual to refresh your knowledge. Always prioritize your well-being and follow the instructions of emergency personnel.
Child Safety Seat Installation
Ensuring the safety of children is paramount when traveling in your 2016 Subaru Outback. Proper child safety seat installation is crucial and must adhere to all local laws and regulations. The Outback is equipped with LATCH (Lower Anchors and Tethers for CHildren) and tether anchors for secure installation.
Always refer to both the child safety seat’s instruction manual and this vehicle owner’s manual for detailed guidance. Incorrect installation can compromise the seat’s effectiveness in a collision. Carefully follow the steps for securing the seat‚ ensuring it is level and firmly attached.

Never place a rear-facing infant seat in front of an active airbag. Regularly check the tightness of the installation and the harness straps. Prioritize using the appropriate seat for your child’s weight and height. Consult a certified Child Passenger Safety Technician for assistance if needed.
